suitable materials and application
Suitable for welding of kettle, vacuum cup, stainless steel bowl, sensor, tungsten wire, high power diode , aluminum
alloy, laptop shell, mobile phone battery, door handle, Molds, electric apparatus fittings, filter, nozzle, stainless steel
products, golf head, zinc alloy artworks.
It can do Weld point, straight line, circle, square ,weld vertical track.
Usage Limitations: High Initial Investment—The unit cost of the equipment is significantly higher than that of traditional welding machines. Thickness Limitations—For exceptionally thick steel plates exceeding 8 mm, both welding efficiency and penetration depth performance fall short of traditional welding processes. Safety Requirements—Given that laser radiation poses a risk of injury to human eyes and skin, operators must wear specialized laser safety goggles during operation and ensure that the work area is adequately shielde
Model | 1000W丨 1500W 丨 2000W丨 3000W |
Laser Wave length | 1060nm |
Welding Thickness | 0.3-6.0mm |
Welding Speed | 0.7-2.0m/min |
Fiber | 50um，10m |
Modulation frequency | 20KHz |
Energy stability | <3% |
Cooling medium | Distilled water/Pure water |
Continuous working time | 24 hours |
Welding method | pulse，continuous |
Consumables | Protect lenses，Protect gas |
Spot diameter | 0-4mm |
Power | 4KW丨6KW 丨 8KW 丨10W |
Electrical Power Source | 220V/380V |
Environment requirements | Clean and dust-free; temperature: 13℃-28℃，humidity: 5%-75% |
laser cleaning size | 50MM |
